DIN to Tri-Clamp Hygienic Elbow – 45° / 90°

Polished stainless steel hygienic elbow connecting DIN to Tri-Clamp, available in 45° and 90° versions.

Options

• Tube sizes: 1", 1.5", 2", 2.5", 3" and 4".
• Choose the bend angle and connection combination from the options above.
• Both weld ends match the selected tube size.
• 316L stainless steel bend and weld-on connection ends.
• Female RJT or DIN connections include a 304 stainless steel nut and 316L liner.
• DIN Male connections include a blue EPDM joint ring.
• Tri-Clamp end supplied as a ferrule; clamp and gasket are not included.

DIN connections have imperial weld ends: 1" / DN25, 1.5" / DN40, 2" / DN50, 2.5" / DN65, 3" / DN80 and 4" / DN100.
